Nkoj Lifting Gantry Crane
Rated Lifting Moment: Customizable
Lifting Qhov siab: Cov neeg siv khoom xav tau
Txoj kev tswj hwm: tswj chaw taws teeb
Tom qab Warranty Service: Video technical support
Xim: Customized
Qhov xwm txheej: Tshiab
Warranty: 5 Xyoos
Qhov chaw ntawm Keeb Kwm: Henan, Suav
Hauj lwm lawm
nkoj lifting gantry crane Description
Lub nkoj mobile crane feem ntau yog siv rau kev tu txhua hnub ntawm 50-1200t yachts. Nws tuaj yeem paub txog 12 hom kev taug kev xws li linear motion, tilting motion, line motion, rotation thiab Ackerman steering kom tau raws li qhov xav tau ntawm cov xwm txheej sib txawv.
Cov khoom yog tsav los ntawm tag nrho cov hydraulic siab, nrog lub hwj chim mov thiab zoo fluidity. Lub ntsiab kawg beam yog hinged kom tshem tawm txoj kev nyuaj siab los ntawm txoj kev tsis sib xws. Lub lifting mechanism siv lub load-rhiab heev hydraulic system los tswj synchronous nqa ntawm ntau lub ntsiab lus nqa. Tso zis hluav taws xob tso zis nyob rau hauv cov xwm txheej load kom txo tau tag nrho lub zog noj
Lub nkoj txawb crane yog lub tshuab hoisting tshwj xeeb, siv rau cov nkoj ua haujlwm thiab kev thauj mus los kab rov tav, feem ntau yog siv rau crane kev khiav hauj lwm mechanisms xws li cov ntug hiav txwv dej.
Khoom nta ntawm nkoj crane
Zoo heev txhim kho qhov yooj thiab ntau lawm efficiency ntawm ntau lawm
Kev ua haujlwm siab, kev ntseeg siab, thiab kev ua haujlwm raug txo qis kev ua haujlwm thiab kev siv zog
nkoj Crane Parameters
| Load peev | Lifting ceev m/min | Taug kev Ceev m/min | Maximum Gradeability | Lifting Mechanism/Lifting Point Number | Diesel Cav kw | |
| Load tag nrho | Empty Load | |||||
| 32t | 0~3 | 0~4 | 0~30 | 4 feem pua | 4/4 | 90 |
| 50t | 0~1 | 0~3 | 0~30 | 4 feem pua | 4/4 | 110 |
| 64t | 0~1 | 0~3 | 0~30 | 4 feem pua | 4/4 | 110 |
| 100t | 0~1 | 0~3 | 0~20 | 4 feem pua | 4/8 | 120 |
| 150t | 0~1 | 0~3 | 0~20 | 4 feem pua | 4/16 | 120 |
| 200t | 0~1 | 0~3 | 0~30 | 4 feem pua | 4/16 | 150 |
| 300t | 0~1 | 0~3 | 0~20 | 4 feem pua | 4/32 | 250 |
| 350t | 0~1 | 0~3 | 0~25 | 4 feem pua | 4/32 | 230 |
| 400t | 0~1 | 0~3 | 0~25 | 4 feem pua | 4/32 | 300 |
| 500t | 0~1 | 0~3 | 0~25 | 4 feem pua | 8/32 | 2x130 |
| 550t | 0~1 | 0~3 | 0~25 | 4 feem pua | 8/32 | 2x150 |
| 600t | 0~1 | 0~3 | 0~20 | 4 feem pua | 8/32 | 2x185 |
| 700t | 0~1 | 0~3 | 0~10 | 4 feem pua | 8/32 | 2x200 |
| 800t | 0~1 | 0~3 | 0~10 | 4 feem pua | 8/32 | 2x230 |
