50 Tuj Rail Mounted Thawv Gantry Crane
Khoom npe: rail mounted Thawv gantry crane
Feature: Gantry Crane
Max. Lifting Qhov siab: 13m
Ntev: 18-35m
Chav ua haujlwm: A6-A8
Industrial Voltage: Raws li koj qhov kev thov
Qhov chaw ntawm Keeb Kwm: Henan, Suav
Warranty: 5 Xyoos
Cov xwm txheej: Cov khoom tshiab
Hauj lwm lawm
Container Gantry Crane Model Description
Covrail-mounted thawv gantry craneyog tsim los ntawm lub ntsiab beam, nruj thiab saj zawg zog qhov rooj ob txhais ceg, khiav trolley, lifting mechanism, lub laub khiav mechanism, hluav taws xob system, kev khiav hauj lwm cab, thiab lwm yam. qhov rooj ceg los yog nyob rau hauv cov kev taw qhia ntawm ob lub qhov rooj ob txhais ceg, nws yuav ua tau ib tug tib cantilever los yog ob chav cantilever qauv, thiab yog hais tias nws tsis yog ncua, nws yuav ua tau ib tug non-cantilever qauv. Raws li qhov chaw, cov txheej txheem ntim khoom thiab kev thauj mus los, thiab kev thauj khoom thiab thauj cov tsheb thauj khoom (cov tsheb thauj khoom lossis tsheb ciav hlau), cov qauv sib txawv tsis muaj cantilever, ib qho cantilever thiab ob chav cantilever yog siv.
Thawv Gantry Crane Model Parameters
|
Caoacutt ntawm Spreader |
T | 30.5 | 35 | 40.5 | 50 | ||
|
Ua Haujlwm Ua Haujlwm |
A6 | A6 | A6 | A6 | |||
|
Ntev (m) |
S | 35 | 35 | 35 | 35 | ||
|
Hauv paus (m) |
B | 16 | 16 | 16 | 16 | ||
|
Lifting qhov siab (m) |
H | 15.4 | 15.4 | 18.2 | 18.2 | ||
| Ceev | Hoisting | Nrog Full load |
m/min |
12 | 12 | 18 | 18 |
| Tsuas yog Winty Spreader | 24 | 24 | 36 | 36 | |||
| Tsheb thauj mus los | 60 | 60 | 70 | 70 | |||
| Mus ncig | 45 | 45 | 45 | 45 | |||
|
Tag Nrho Lub Zog |
kws |
~200 |
~230 |
~255 |
~300 |
||
|
Max. ua hauj lwm Load of Log |
kn |
260 | 260 | 280 | 300 | ||
|
Crane Rail |
|
P50 | P50 | P50 | qw 80 | ||
|
Hwj chim Source |
Peb-theem AC 50Hz 380V |
||||||
Container Gantry Crane Model Nta
1. Lub lifting ceev yog tsawg thiab khiav ceev ntawm lub laub yog siab
2. Kev khiav ceev ntawm lub trolley tuaj yeem txiav txim siab raws li qhov ntev ntawm tus choj thiab kev nthuav dav ntawm ob qho kawg
3. Thaum lub sijhawm ncua ntev tshaj 40m, thaum lub sijhawm ua haujlwm siab ntawm lub laub, qhov sib txawv yuav tshwm sim vim qhov sib txawv khiav ntawm lub qhov rooj ob txhais ceg ntawm ob sab. Rau lub hom phiaj no, ib tug synchronization ntaus ntawv yog ntsia los tswj lub synchronization ntawm khiav ceev ntawm lub khiav mechanisms ntawm ob sab los ntawm cov hluav taws xob tswj system.
4. Yuav kom ua tau raws li qhov xav tau ntau dua rau kev siv, lub zog tsav hluav taws xob tswj tau txais thyristor DC lossis AC ceev tswj kev tswj hwm qhov system kom ua tiav cov kev cai ceev thiab tswj kev ua haujlwm.
Thawv Gantry Crane Hlau qauv
Steel qauv ntawm lubrail-mounted thawv gantry cranefeem ntau txais yuav lub thawv qauv. Txhawm rau txo qhov hnyav ntawm tag nrho lub tshuab, cov qauv truss tuaj yeem siv tau, tab sis tus nqi tsim khoom kuj tseem siab.
Cov qauv ntawm tag nrho lub tshuab txais "Π" hom thiab "U" hom nyob ntawm seb txoj kev txhawb nqa ntawm lub qhov rooj ob txhais ceg. Lub qhov rooj nruj thiab hloov tau yooj yim ntawm "Π" hom qauv yog ob qho tib si "Π" cov ntaub ntawv. Lub zog thiab rigidity ntawm txhais ceg nws tus kheej yog paub los ntawm lub rigidity ntawm lub qhov rooj ceg thiab lub nqaj ntawm lub qhov rooj ceg. Lub qhov rooj ceg ntawm tus qauv "U" yog pom tau los ntawm kev sib txuas nruj ntawm lub qhov rooj ceg thiab sab qis ntawm lub qhov rooj ceg.
Thawv Gantry Crane Model Drawing
Nco ntsoov
- Cov ntaub ntawv dab tsi kuv yuav tsum muab thaum nug?
1. Xav paub ntau ntxiv lossis kos duab, zoo dua.
2. Nqa muaj peev xwm
3. Npog
4. Nqa qhov siab
5. Lub zog los yog lwm yam tshwj xeeb uas koj muab rau peb yuav txaus siab rau ntau dua.
