Kab rov tav Pulling Electric Wire Winch
Warranty: 3 xyoos
Qhov chaw ntawm Keeb Kwm: Henan Tuam Tshoj
Control: Chaw taws teeb tswj Nias khawm tswj
Lub luag haujlwm ua haujlwm: A3 ~ A5
Fais fab mov: 3 Theem 380V 50Hz
Xim xim: Raws li koj xav tau
Hauj lwm lawm
Kab rov tav rub hluav taws xob hlau winch
Product Description
hluav taws xob winch 5 tuj yog ib yam khoom siv lub teeb thiab me me uas siv cov hlua khi los qhwv cov hlua hlau los yog saw nqa los yog rub cov khoom hnyav vertically, horizontally lossis tilted. Nws tuaj yeem siv ib leeg, thiab tseem yog cov khoom siv ntawm ntau yam khoom siv, xws li gantry crane, kev tsim kho, mine, shipyard, thiab lwm yam.
Khoom Drawings ntawm Kab rov tav rub hluav taws xob hlau winch
Cov yam ntxwv ntawm Kab rov tav rub hluav taws xob hlau winch:
1. Muaj ntau yam
2.Compact qauv
3.Me me
4. Lub teeb nyhav
5.Great lifting gravity
6. Yooj yim rau siv
FAQ:
Q: Kuv puas tuaj yeem tso qhov kev txiav txim ncaj qha?
A: Yog.
Q: Peb puas tuaj yeem ua nws raws li peb cov duab kos? A: Peb tuaj yeem kho cov khoom raws li koj cov duab kos. Nug, Kuv puas tuaj yeem mus rau lub tuam txhab kuaj xyuas? Teb, txais tos tuaj xyuas koj lub tuam txhab kev taw qhia.
Q: Puas yog cov khoom lag luam zoo lav? A: Lub tuam txhab cov cuab yeej siv tshuab kuaj tshuab, khoom warranty rau 5 xyoos.
Technical parameter ntawm 10t fais winch
Basic Parameters | Rated Load | Nruab Nrab Ceev ntawm txoj hlua | Muaj peev xwm ntawm txoj hlua | Txoj kab uas hla | Lub cev muaj zog | Zuag qhia tag nrho Dimension | Qhov hnyav tag nrho |
Qauv | KN | m/min | m | mm | KW | mm | kg |
| JM 1 | 10 | 15 | 100 | 9.3 | 3 | 620×701×417 | 270 |
| JM 1.6 | 16 | 16 | 150 | 12.5 | 5.5 | 945×996×570 | 500 |
| JM 2 | 20 | 16 | 150 | 13 | 7.5 | 945×996×570 | 550 |
| JM 3.2 | 32 | 9.5 | 150 | 15.5 | 7.5 | 1430×1160×910 | 1100 |
| JM3.2B | 32 | 12 | 195 | 15.5 | 7.5 | 1082×1014×610 | 536 |
| JM 5 | 50 | 10 | 270 | 21.5 | 11 | 1235×1230×805 | 1560 |
| JM5B | 50 | 9.5 | 200 | 21.5 | 11 | 1620×1260×945 | 1800 |
| JM5C ua | 50 | 9.5 | 350 | 21.5 | 11 | 1235×1230×805 | 1800 |
| JM5D | 50 | 15 | 350 | 21.5 | 15 | 1235×1230×805 | 1850 |
| JM5E | 50 | 20 | 350 | 21.5 | 22 | 1235×1230×805 | 2000 |
| JM 20 | 200 | 10 | 600 | 43 | 45 | 3950*2560*1950 | 9900 |
| JM 25 | 250 | 9 | 700 | 48 | 55 | 4350*2800*2030 | 13500 |
| JM 32 | 320 | 9 | 700 | 56 | 75 | 4500*2850*2100 | 14800 |
| JM 50 | 500 | 9 | 800 | 65 | 90 | 4930*3050*2250 | 19500 |
| JM65 | 650 | 10.5 | 3600 | 64 | 160 | 5900*4680*3200 | 46000 |
| Peb tuaj yeem tsim thiab tsim txhua yam ntawm cov khoom tsis-tus qauv raws li koj qhov yuav tsum tau ua |
Cov duab ntxaws
Cov duab khoom
Packing & shipping
Cim npe nrov: kab rov tav rub hluav taws xob hlau winch Tuam Tshoj, manufacturers, lwm tus neeg, customized, quotation, kev, nqe
