Truss Hom 100 Tuj Beam Launcher
Tus chij liab liab hom choj choj crane thiab kev ua qauv ua choj choj lub nkoj tau koom rau ntawm pawg no, thiab qhov hnyav hoisting tseem yog 130 tons.
Lub jib yog tsim ntawm ob sab laug thiab sab xis kab teeb uas hla cov fuselage thiab txuas ntxiv mus rau tom ntej thiab rov qab.
Hauj lwm lawm
Truss Hom 100 Tuj Beam Launcher
Daim Ntawv Thov Khoom
260T U beam beam launcher chaw tsim tshuaj paus rau LRT qhov project yog siv rau kev txhim kho pob zeb ua kab thaiv kab hluav taws xob rau kev kub ceev (250km, 350km) neeg caij tsheb ciav hlau kab. Lub tshuab no haum rau kev sib npaug ntawm cov girders lossis txawv girders uas tuaj yeem ua tau 20m, 24m thiab 32m, 50m. Sab nraub qaum muaj ob qho kev txhawb nqa. Ib qho ntawm cov kev txhawb nqa yog" C" cov duab kab nrog cov thev naus laus zis thiab khawm." C" cov duab kem thev naus laus zis thev naus laus zis nrhiav chaw hla thaum mus ncig thiab uas tuaj yeem taug kev hla kev nrog cov girder hloov tsheb.
Max Mev | 50m | 40m | 35m | 30m |
| Hoist Muaj Peev Xwm | 160t | 100t | 80t | 60t |
| Lifting Ceev ntawm Trolley | 0.8m / min | 0.8m / min | 0.8m / min | 0.8m / min |
| Tsiv Sspeed ntawm Trolley | 4.5m / min | 4.5m / min | 4.5m / min | 4.5m / min |
| Kev txav ceev ntawm Crane | 2.7m / min | 2.7m / min | 2.7m / min | 2.7m / min |
| Chaw thau khoom muaj peev xwm | 80t×2 | 50t×2 | 40t×2 | 30t×2 |
| Kev Ruam ntawm Kev Thauj Khoom Hnyav | 4-8m / min | 4-8m / min | 4-8m / min | 4-8m / min |
| Qhov ceev ntawm Npliag Thauj Khoom | 18m / min | 18m / min | 18m / min | 18m / min |
| Max Lub kaum sab xis ntawm Inclined Choj | 45° | 45° | 45° | 45° |
Txoj Kev Them Nqi
Ntawm no qhia koj tus nqi kwv yees EXW ntawm peb cov khoom rau koj saib ua ntej. Tus nqi no tsuas yog rau siv rau koj cov peev nyiaj, yog tias muaj kev txaus siab thov nias" Ntau" kom pom cov ncauj lus kom ntxaws nqi.
| EXW PRICE LIST RAU KOJ LUS TSHAJ | Cov ncauj lus kom ntxaws | |||
| Thauj khoom muaj peev xwm | Hlua qhov ntev | |||
| 40m | 50m | 55m | Ntau>> | |
| 50t | Teb Chaws Asmeskas $ 136000.00 | Teb Chaws Asmeskas $ 148000.00 | Teb Chaws Asmeskas $ 168500.00 | Ntau>> |
| 100t | US $ 181100.00 | Teb Chaws Asmeskas $ 205500.00 | US $ 235500.00 | |
| 160t | US $ 243500.00 | US $ 285500.00 | Teb Chaws Asmeskas $ 305500.00 | Ntau>> |
| 200t | US $ 328500.00 | US $ 375500.00 | Teb Chaws Asmeskas $ 405500.00 | Ntau>> |
| 250t | US $ 427700.00 | Teb Chaws Asmeskas $ 458500.00 | Teb Chaws Asmeskas $ 502500.00 | Ntau>> |
1.Hoist thiab qhov hluav taws xob yuav tau ntim los ntawm plywood crate, rau kev zam kom tsis txhob tawm ntawm cov khoom tawg thiab cuam tshuam thaum lub sijhawm khoom xa tuaj.
2.Girders thiab lwm qhov chaw tseem ceeb yuav tau ntim los ntawm cov ntaub qhwv yas, rau kev tiv thaiv xeb los ntawm soppy lub sijhawm thaum lub tsheb thauj mus los.
3. Tsuas yog qhov zoo tshaj plaws kev thauj xa mus los rau kev txuag koj cov nqi tshaj plaws ntawm nyiaj txiag, kev ruaj ntseg thiab sijhawm.
Lub Tuam Txhab Muaj Zog
Henan Dowell Crane Co., Ltdis yog Tuam Tshoj-ua pab pawg ntawm cov lag luam crane uas tau tsim hauv xyoo 1955, Thiab muab kev pabcuam rau cov neeg siv khoom thoob plaws ntiaj teb kom ua tiav cov txheej txheem ua kom tiav nqa, suav nrog Gantry crane, Choj crane, Jib crane, Cov Khoom Siv.
a) .Henan Dowell Crane Co., Ltdhas twb tau CCC, CE, BV, SGS, ISO OHSAS cov ntawv pov thawj thiab tau yeej dhau 60 honors.
b) .Our lub tuam txhab muab kev pab cuam rau ntau tshaj 5000 tuam txhab, thiab cov khoom lag luam yog polular hauv ntau tshaj 100 tus neeg.
Cim npe nrov: Truss Hom 100 Tuj Beam Launcher, tuam ntxhab, gantry launcher, lwm tus neeg, lag luam, customized, quotation, choj nqaj launcher, nqe
